Transparent event tents outdoor wedding for sale
1. Introduction of Transparent event tents outdoor wedding
The clear span of the Big Tent-BT Series is 10m, 12m, 15m, 20m, 21m, and 25m. The main profile size is 204X120X4mm and the modular structure can be increased and decreased in bay distance of 5m according to the clients’ request.
2. Application of Transparent event tents outdoor wedding
The tent attached is our 20X25m tent for 500 people party tent, it is equipped with clear windows, decoration roof lining, inside curtain, pagoda tent 5X5m entrance tent. The tent series are widely used as the party tent, wedding tent, exhibition tent, conference tent, festivals celebration tent, corporate events tent or other events, etc^
3. Specification of Transparent event tents outdoor wedding (BT series)
Main frame profile size for BT series: 204X120X4mm
Wind load: 100km/h
Eave/Corner Connection: Hot-DIP galvanized
Minimum tent length: In order to reach the designed wind load and make sure the tent is safe, please set up the tent with the required minimum tent length.
4. Optional Accessories of Transparent event tents outdoor wedding
-Sidewalls with clear windows
-Ground anchors
-Weight plate
-Lining
-Glass wall system
-Glass door units
-ABS walling system
-Clear roof covers and sidewalls
-Flooring system
-Rain gutter system
-Hexagonal and octagonal end bays and high peak
5. Materials of Transparent event tents outdoor wedding
Fabric: Double PVC coated polyester fabric, 750-900g/sq. M, water proof, UV resistance, fire retardant according to standard NFPA701, CFM & DIN4102 B1/M2
Frame: Hard pressed extruded aluminum 6061/T6, anodized surface finishing.
Connections: Hot-DIP galvanized
6. Colors available
White, red, yellow, blue, green, black, grey, transparent etc
7. Product certificates:
Fabric: Test reports for the fire retardant, standards: NFPA701, CFM & DIN4102 B1/M2
Structure safety: Certificates by the registered engineers in the U. S. A & Australia.
8. Why Choose Us
1) The first tent manufacturer in China- Focus on tent industry for 17 years.
2) The largest tent manufacturer in China which covers 30, 000sqm and includs 20, 000sqm building area.
3) The most reliable tent supplier and the biggest tent exporter in China.
4) Engieer’s company, we concern more about the quality and service.
| Big Tent Series | ||||||||
| Model No. | Width (m) | Length(m) | Eave height (m) | Ridge height (m) | Bay distance (m) | Roof pitch | Longest parts (m) | Max. wind load |
| BT10m/400 | 10 | 10m+5m more | 3.88 | 5.53 | 5 | 18° | 5.97 | 100km/h |
| BT12m/400 | 12 | 10m+5m more | 3.88 | 5.83 | 5 | 18° | 6.5 | |
| BT15m/400 | 15 | 10m+5m more | 3.88 | 6.3 | 5 | 18° | 8.1 | |
| BT18m/400 | 18 | 10m+5m more | 3.88 | 6.6 | 5 | 18° | 10.07 | |
| BT20m/400 | 20 | 10m+5m more | 3.88 | 7.1 | 5 | 18° | 10.07 | |
| BT21m/400 | 21 | 10m+5m more | 3.88 | 7.25 | 5 | 18° | 11.24 | |
| BT25m/400 | 25 | 10m +5m more | 3.88 | 7.88 | 5 | 18° | 10.7 | |
| General Package:1.Aluminum Frame–membrane film 2.Hardware–solid carton box 3. Tent cover–PVC carry bag. | ||||||||
| Note: The longest parts determine the kinds of containers you use to transport the cargo. | ||||||||
| 20 feet container: Inner size: 5.69×2.13×2.18m; Usable Volume: 24-26CBM; Allowed Weight: 17.5 ton | ||||||||
| 40 feet container: Inner size: 11.8×2.13×2.18m; Usable Volume: 54CBM; Allowed Weight: 22 ton | ||||||||
| 40 feet high cube container: Inner size: 11.8×2.13×2.72m; Usable Volume: 68CBM; Allowed Weight: 22 ton | ||||||||
